HPRT TP80K Programming Manual

GS ( L pL pH m fn a kc1 kc2 b xL xH yL yH [c d1...dk]1...[c d1...dk]b
<Function 84>
GS 8 L p1 p2 p3 p4 m fn a kc1 kc2 b xL xH yL yH [c d1...dk]1...[c
d1...dk]b
[Name]
Define the downloaded graphics data (column format).
[Format]
ASCII
GS
(
L
pL
pH
m
fn
a
kc1 kc2 b xL xH yL yH [c d1...dk]1...[c
d1...dk]b
Hex
1D
28
4C
pL
pH
30
54
30
kc1 kc2 b xL xH yL yH [c d1...dk]1...[c
d1...dk]b
Decimal
29
40
76
pL
pH
48
84
48
kc1 kc2 b xL xH yL yH [c d1...dk]1...[c
d1...dk]b
ASCII
GS
8
L
p1
p2
p3
p4
m
fn a kc1 kc2 b xL xH yL yH [c
d1...dk]1...[cd1...dk]b
Hex
1D
38
4C
p1
p2
p3
p4
30
54 30kc1 kc2 b xL xH yL yH [c
d1...dk]1...[cd1...dk]b
Decimal
29
56
76
p1
p2
p3
p4
48
84 48kc1 kc2 b xL xH yL yH [c
d1...dk]1...[cd1...dk]b
[Range]
12 ≤ (pL + pH × 256) ≤ 65535 (0 ≤ pL ≤ 255, 0 ≤ pH ≤ 255)
[When using GS 8 L:12 ≤ (p1 + p2 × 256 +p3 × 65536 + p4 × 16777216) ≤
4294967295]
m = 48, fn = 84, a = 48
32 ≤ kc1 ≤ 126
32 ≤ kc2 ≤ 126
0 ≤ d ≤ 255
k = (xL + xH × 256) × (int((yL + yH × 256) + 7)/8)
[Description]
Defines the downloaded graphics data (column format) as a record specified by the
key codes (kc1 and kc2)
in the downloaded graphics area.
• b specifies the number of colors for the defined data.
• xL and xH specify the number of dots in the horizontal direction as (xL + xH ×
256).
• yL and yH specify the number of dots in the vertical direction as (yL + yH ×
256).
• c specifies the color of the defined data.
c
Color specification
49
Color 1
50
Color 2
51
Color 3
• d specifies the defined data (raster format).
• k indicates the number of the definition data. k is an explanation parameter;
therefore it does not need to be transmitted.
■ In cases where the specified key code already exists in memory, it will be
necessary to overwrite the data.
