3. Perform quick settings.
Table 5-10 Settings Wizard
Item Parameter Setting
Language - Set as required.
Data and
Time
Date format Set as required.
YYYY-MM-DD Actual date
Time zone Actual time zone
Time (H:M:S) Actual time
Network
Param.
IP address assign DHCP Automatic
System
Param.
Rated frequency Set as required.
Rated line voltage Set as required.
4. Check whether there is any alarm on the monitoring screen. If there is, clear
it.
5. Turn on the input switch in the PDF.
After the input switch in the PDF is turned on, the MDU will report a Branch Disconnected
alarm, which is a normal phenomenon.
Step 6 Switch on the network cabinet output circuit breaker in the PDF and switch on the
rPDU input circuit breaker in the network cabinet to power on the network
cabinet.
Step 7 Switch on the IT cabinet output circuit breakers in the PDF one by one and switch
on the rPDU input circuit breakers in the IT cabinets to power on the IT cabinets.
● When switching on an output circuit breaker, check whether the mapping between the
circuit breaker and the downstream device is consistent with that in the design drawing.
● Do not switch on the reserved circuit breakers.
● When switching on the circuit breakers, observe whether there is any abnormal
phenomenon, such as sparks or unsmooth switching.
Step 8 After switching on an IT output circuit breaker, check whether the corresponding
Branch Disconnected alarm on the MDU screen disappears. The Branch
Disconnected alarm generated for a reserved circuit breaker can be masked on the
MDU screen.
To mask alarms, choose System info. > Settings and tap Alarm Masking.
----End
FusionModule2000-S Smart Modular Data Center
User Manual 5 Power-On Commissioning
Issue 07 (2022-09-30) Copyright © Huawei Technologies Co., Ltd. 148
