6. Set Leak sensor to Enable and click Submit.
7. Conrm that Leak sensor type is automatically identied as Leak
sensor(Rope).
Step 2 Check the function of the water sensor.
Check Method Normal Connection
Status
Alarm Clearance
Method
Immerse the water
detection cable in water.
Leak DI alarm is
displayed on the active
alarm page of the app or
WebUI.
Wipe dry the water
detection cable. The
alarm disappears
automatically.
----End
5.3.8.4 Commissioning the Electrode Water Sensor
If a water sensor is installed, perform the following steps to congure it.
Prerequisites
One end of the network cable has been stripped, core wires 7 and 8 have been
connected to the cable delivered with the electrode water sensor, and the other
end of the network cable has been connected to the AI/DI port on the rack
environment unit.
Context
To use the AI/DI sensor, enable the corresponding AI/DI port and name the
sensor. The
specic alarm then can be reported.
If the sensor is prefabricated, only check its settings.
The actual value prevails. Only the method of the parameter settings is
described.
Procedure
Step 1 Set water sensor parameters.
NO TE
The following describes how to connect a water sensor to the AI/DI_2 port on the ECC800-
Pro.
1. Log in to the ECC800-Pro WebUI as an administrator.
2. Choose System Settings > Signal Name Modify. The Batch Signal
Conguration page is displayed.
3. Set Device type to ECC800, set Device name to ECC800, and click OK.
4. On the query result tab page, set the new signal name of AI/DI_2 to Leak
and click Submit.
5. Choose Monitoring > System > ECC800 > Running Parameters > AI/DI_2
Port Settings.
FusionModule500 Smart Mini Data Center
User Manual 5 Power-On Commissioning
Issue 02 (2020-12-25) Copyright © Huawei Technologies Co., Ltd. 175
