Cable
NO TICE
● The site ground resistance must be less than 0.1 ohm.
● The cable re resistance rating must be at least VB.
Table 4-8 Cable specications
Application Scenario Specications Remarks
(Optional) Outdoor unit
power cable
Electrical power cable,
600 V, ZA-RVV, 4 x 2.5
mm
2
, black (four core
wires: brown, black, blue,
yellow/green), 46 A,
outdoor cable, CE
The length is determined
based on site survey.
Common terminal,
single-wire cord end
terminal, 2.5 mm
2
,
insertion depth 12 mm,
blue
Delivered with the
ttings
Bare crimp terminal, OT,
2.5 mm
2
, M4, tin plated,
16–14 AWG
Delivered with the
ttings
4.2.4.2 Layout Principles
The layout principles are as follows:
● If the outdoor unit is placed higher than the indoor unit, the maximum height
deviation between them should be less than or equal to 20 m. Install an oil
trap every 6 m to 7.5 m along the gas pipe in the vertical direction to ensure
system reliability.
● If the indoor unit is placed higher than the outdoor unit, the maximum height
deviation between them should be less than or equal to 5 m.
NO TICE
● The height deviation refers to the distance between the stop valve of the
indoor unit and that of the outdoor unit.
● is a sign of a tilt, and indicates that the scale of the pipe tilting is at
least 1:200. The pipe tilting direction should be consistent with the hypotenuse
of the right triangle.
FusionModule500 Smart Mini Data Center
User Manual 4 Installation Guide
Issue 02 (2020-12-25) Copyright © Huawei Technologies Co., Ltd. 75
