Step 4 Reconnect the cables to the new IVS1800.
Step 5 Turn on the power switch of the IVS1800.
Step 6 Commissioning the IVS1800. If the video recording function works properly after
commissioning, the IVS1800 is functional.
----End
6.4.3.8 Replacing a Hard Disk for the IVS1800
Prerequisites
● A hard disk needs to be replaced.
● Data in the hard disk has been backed up.
● A spare hard disk of the same model is available and functional.
● Before replacing a faulty disk, ensure that the power switch on the rear panel
is o and disconnect the power cable to power o the device.
Context
Recommended tools and materials: Phillips screwdriver, ESD wrist strap (or ESD
gloves).
Procedure
Step 1 Put on an ESD wrist strap (or ESD gloves) and insert the ground terminal into the
ESD jack in the cabinet.
Step 2 Remove the faulty hard disk.
1. Use a PH2 screwdriver to remove the two black screws on the rear of the
chassis cover, and take
o the chassis cover.
Figure 6-19 Removing the chassis cover
2. Remove two black screws on each side of the chassis and the silvery white
one on top of the hard disk tray, raise the hard disk tray by 45 degrees, and
take out the upper and then lower layers of hard disk tray.
Figure 6-20 Removing the hard disk tray
FusionModule500 Smart Mini Data Center
User Manual 6 O&M
Issue 02 (2020-12-25) Copyright © Huawei Technologies Co., Ltd. 281
