Figure 6-23 Connecting data and power cables to hard disks
4. Close the chassis cover, and use a PH2 screwdriver to fasten the rear screws.
Figure 6-24 Closing the chassis cover
Step 4 Observe the hard disk indicator to check whether the hard disk works properly.
----End
Follow-up Procedure
If the hard disk works abnormally, contact Huawei technical support.
6.4.3.9 Replacing a T/H Sensor (33010516)
Prerequisites
● A T/H sensor needs to be replaced.
● A spare T/H sensor of the same model is available and functional.
Procedure
Step 1 Tap Shutdown on the controller home screen.
Exercise caution because the device is still energized after it is shut down on the
controller home screen.
FusionModule500 Smart Mini Data Center
User Manual 6 O&M
Issue 02 (2020-12-25) Copyright © Huawei Technologies Co., Ltd. 283
