If You
Need
To...
Then...
2. Add lter conditions, select multiple smart modules, and click
Delete.
3. In the displayed
Conrm dialog box, click Yes.
Add tools
1. Select the smart module for which you want to add a pillar.
2. In the lower left corner of the current page, click Tool.
3. Select the Pillar component to be added.
NOTE
After the component is added, you can set attributes for the component
in the Component Info list in the right pane. The system automatically
displays values for Parent Name and Control Type, and you do not need
to manually set them, you only need to set Name.
4. In the upper area of the current page, click
.
5.3.13.1.10 Creating an ECC800-Pro on the NetEco
Prerequisites
● You have logged in to the NetEco client using a web browser.
FusionModule500 Smart Mini Data Center
User Manual 5 Power-On Commissioning
Issue 02 (2020-12-25) Copyright © Huawei Technologies Co., Ltd. 226
