Figure 4-43 Installing PDU2000s
----End
4.2.6 Installing Monitoring Devices
4.2.6.1 Installing the SIM Card and Antenna
If a subscriber identity module (SIM) card and an antenna are
congured, perform
the following steps to install them.
Procedure
Step 1 Record the positions of the signal cables connected to the panel of the ECC800-
Pro main control module, and then disconnect the signal cables.
Step 2 Remove the ECC800-Pro main control module, and then insert the SIM card into
the left slot of the ECC800-Pro main control module.
The SIM card needs to support LTE, WCDMA, or GSM.
FusionModule500 Smart Mini Data Center
User Manual 4 Installation Guide
Issue 02 (2020-12-25) Copyright © Huawei Technologies Co., Ltd. 103
