Huawei FusionModule500 User Manual

Check Item Specications Check Result
Equipment room
height
≥ 2.6 m □ Passed □ Failed
Equipment room
area
≥ 10.15 m
2
□ Passed □ Failed
Equipment room
maintenance
clearance
At least 1200 mm, 1000 mm,
and 1200 mm maintenance
clearance should be reserved at
the front door, rear, and side of
the cabinet, respectively. The
cabinet can be installed against
the wall.
□ Passed □ Failed
Power system 220 V/230 V/240 V, 1 Ph, 50
Hz/60 Hz
□ Passed □ Failed
Water port Condensate drain outlet: Drains
condensate water from the
smart cooling product.
□ Passed □ Failed
Humidier water pipe port:
Connects to external water
pipes to supply water to the
humidier.
□ Passed □ Failed
NO TE
If any of the requirements is not met, contact Huawei technical support.
4.1.3 Site Equipment Preparation
● All cabinets and devices have been delivered to the site and checked against
the delivery list.
● Cabinets and devices need to be transported to the specied positions based
on the detailed equipment room layout diagram and unpacked for further
installation.
CA UTION
Pay attention to the following when unpacking batteries:
● Insert a at-head screwdriver into the gap between the wooden crate and its
top cover. Then pry
o the top cover along the external edge of the cover until
the cover can be taken out from the crate.
● Be careful to prevent your hands from being hurt by nails during unpacking.
FusionModule500 Smart Mini Data Center
User Manual 4 Installation Guide
Issue 02 (2020-12-25) Copyright © Huawei Technologies Co., Ltd. 61
