Figure 6-7 Removing the ECC800-Pro main control module
Step 5 (Optional) Remove the Micro SD card and SIM card from the corresponding slots
of the ECC800-Pro main control module.
Step 6 (Optional) Install the removed Micro SD and SIM card in the corresponding slots
of the new ECC800-Pro main control module.
Figure 6-8 Installing the Micro SD and SIM card
Step 7 Install the spare ECC800-Pro main control module in the ECC800-Pro subrack and
tighten the screws on both sides of the ECC800-Pro main control module.
Step 8 Connect the communications cables and antennas to the ECC800-Pro main control
module.
Step 9 Choose Maintenance >
Conguration File and import the backup conguration
le,
or set parameters for the devices that connect to the ECC800-Pro to ensure
normal communication.
----End
6.4.3.2 Replacing an ECC800-Pro PSU
Prerequisites
Do not touch the terminals in the rear of a removed PSU to avoid electric shocks.
● Tool: insulation gloves
FusionModule500 Smart Mini Data Center
User Manual 6 O&M
Issue 02 (2020-12-25) Copyright © Huawei Technologies Co., Ltd. 273
