Figure 4-14 Installing an indoor unit
● Remove the desiccant bound to the front panel of the smart cooling product before
installation.
● The indoor unit of the smart cooling product does not have an external indicator. The
main control board inside the indoor unit has an indicator, which can be seen only after
the rear panel is opened.
----End
4.2.4.4 Exhausting Nitrogen from an Indoor Unit
Context
0.5 MPa nitrogen is injected into the indoor unit for transportation.
Nitrogen needs to be exhausted from the indoor unit through the gas pipe needle
valve of the indoor unit stop valve. Figure 4-15 shows a stop valve.
FusionModule500 Smart Mini Data Center
User Manual 4 Installation Guide
Issue 02 (2020-12-25) Copyright © Huawei Technologies Co., Ltd. 77
