Parameter Description
Bit rate control
mode
This parameter is available only when you set Bit rate
type to Constant bit rate. The options are as follows:
– Frame rate priority: Ensure the smoothness of the
video image.
– Image quality priority: Ensure the quality of the
video image.
Frame rate The frame rate is measured by the number of frames
displayed in a second.
A higher frame rate indicates clearer and smoother
images and higher bandwidth consumption.
Image quality This parameter is available only when you set Encoding
protocol to H.264 or H.265 and Bit rate type to
Variable bit rate.
Better image quality requires higher bandwidth.
Therefore, select proper image quality based on the site
requirements.
I-frame interval This parameter is available only when you set Encoding
protocol to H.264 or H.265.
An I frame is an intra-coded frame that represents a
xed image independent of other picture types. Each
group of pictures (GOP) begins with this type of frame.
A smaller I-frame interval indicates better video quality
and higher bandwidth consumption.
Layered
encoding
This parameter is available only when you set Encoding
protocol to H.264 or H.265.
To enable layered encoding, select Layered encoding.
JPEG quality This parameter is available only when you set Encoding
protocol to MJPEG.
A larger value indicates higher image quality.
----End
Follow-up Procedure
Commission other cameras by referring to this section.
5.3.11.3.2 Commissioning a C3220 Camera (SD Card Congured)
Context
If the VCN or IVS1800 is not
congured and an SD card is chosen, perform the
following procedure.
FusionModule500 Smart Mini Data Center
User Manual 5 Power-On Commissioning
Issue 02 (2020-12-25) Copyright © Huawei Technologies Co., Ltd. 192
