Settings Procedure
Set Use Pop-up Blocker to Disable. 1. Choose Tools > Internet
Options.
The Internet Options dialog box
is displayed.
2. Click the Security tab.
3. Select Internet.
4. Click Custom level.
The Security Settings-Internet
Zone dialog box is displayed.
5. Set Use Pop-up Blocker to
Disable.
6. Click OK.
Step 2 Commission cameras and set parameters for them. For details, see the delivered
documents.
1. Preview the site situation in real time and check the camera coverage through
videos. Adjust the lens if necessary.
2. On the View tab page, click the Network/Time tab to access the Network/
Time tab page.
Figure 5-19 Setting the IP address
FusionModule500 Smart Mini Data Center
User Manual 5 Power-On Commissioning
Issue 02 (2020-12-25) Copyright © Huawei Technologies Co., Ltd. 188
