Figure 3-6 ECC800-Pro
(1) Power module (2) Main control module
Table 3-9 ECC800-Pro environmental specications
Item Specications
Operating
temperature
–20°C to +50°C
Storage temperature –40°C to +70°C
Relative humidity 5%–95% RH (non-condensing)
Altitude 0–4000 m (When the altitude is between 3000 m and
4000 m, the temperature decreases by 1°C for each
additional 200 m.)
Table 3-10 ECC800-Pro structural specications
Item
Specications
Dimensions (L x W x H) 442 mm x 330 mm x 43.6 mm
Weight 6.3 kg (with a single power module
and a main control module)
Color Black
Installation requirements Can be installed in a 1 U space in a
standard 19-inch cabinet
Environmental protection RoHS5, REACH, WEEE
FusionModule500 Smart Mini Data Center
User Manual 3 System Architecture
Issue 02 (2020-12-25) Copyright © Huawei Technologies Co., Ltd. 30
