Installation Manual
Quidway S8500 Series Routing Switches Appendix A Engineering Labels for Cables
Huawei Technologies Proprietary
A-10
The label on the alarm cable carries simple information, and only part of the text area
needs to be filled in. It is recommended to keep the whole length of the label instead of
cutting out the blank area.
Figure A-10 shows a label on the alarm cable, on which “A01” indicates that the alarm
cable is connected from the first cabinet to the cabinet on Row A, Column 01 in the
machine room.
Figure A-10 Example of the label on the alarm cable
A.3 Engineering Labels for Ethernet Cables
These labels are affixed to the Ethernet cables that connect the boards in the frames, or
on the cables that connect HUBs and servers or agents of the Value Added Service
(VAS) products.
I. Meaning of the Label
Table A-3 shows the information on both sides of the labels affixed to the Ethernet
cables that connect the boards in the frames.
Table A-3 Information on labels affixed to the Ethernet cables
Content Meaning Example
MN: Cabinet
number
For example, A01
B: Frame
number
Numbered in top-down order with two digits, for
example, 01
C: Physical slot
number
Numbered in top-down and left-right order with
two digits, for example, 01
MN-B-C-D
D: Ethernet port
number
Numbered in top-down and left-right order with
two digits, for example, 01
