Quidway S8500 Series Routing Switches Chapter 1 Product Overview
Huawei Technologies Proprietary
1-16
Table 1-16 Management 10Base-T/100Base-TX port specifications
Attribute Description
Connector RJ-45
Number of ports One
Rate
10 Mbps, half duplex/full duplex
100 Mbps, half duplex/full duplex
Max. transmission segment over
the selected medium
100 m (328 ft) over the category-5 twisted pair
cable (crossover cable is required.)
Service
System program upgrade and network
management
The following table describes the status LEDs for the management
10Base-T/100Base-TX port.
Table 1-17 Status LEDs for the management 10Base-T/100Base-TX port
LED Status
OFF No link is present.
LINK
Green A link is present.
OFF
No packets are transmitted/received on the
port.
ACT
Blinking
Packets are being transmitted/received on the
port.
z
RS232/485 port
The RS232/485 port uses RJ-45 connector, for connecting external PoE power frame
when supported and monitoring its status.
Table 1-18 RS232/485 port specifications
Attribute Description
Connector RJ-45
Number of ports One RS 232 port and one RS485 port
Service
The port for monitoring and communication with the external
subsystem, such as external PoE power supply module
z
Console port
The Console port uses an RJ-45 connector. It can be connected to a background
terminal for system debugging, maintenance, management, and host software loading.
