Quidway S8500 Series Routing Switches Chapter 1 Product Overview
Huawei Technologies Proprietary
1-20
The SRP1N2 module provides a CF port to accommodate a standard CF card, where
you can save logging information, host version information, alarming and other
diagnostic information and conveniently upgrade software online.
z
Management 10Base-T/100Base-TX port
The management 10Base-T/100Base-TX port uses an RJ-45 connector. It can connect
a background terminal for system program loading and debugging, or connect a
network management station for remote system management.
Table 1-25 Management 10Base-T/100Base-TX port specifications
Attribute Description
Connector RJ-45
Number of ports One
Rate
10 Mbps, half duplex/full duplex
100 Mbps, half duplex/full duplex
Max. transmission segment
over the selected medium
100 m (328 ft) over the category-5 twisted pair
cable (crossover cable is required.)
Service
System program upgrade and network
management
The following table describes the status LEDs for the management
10Base-T/100Base-TX port.
Table 1-26 Status LEDs for the management 10Base-T/100Base-TX port
LED Status
OFF No link is present.
LINK
Green A link is present.
OFF No packets are transmitted/received on the port.
ACT
Orange
blinking
Packets are being transmitted/received on the
port.
z
RS232/485 port
The RS232/485 port uses RJ-45 connector, for connecting external PoE power frame
when supported and monitoring its status.
Table 1-27 RS232/485 port specifications
Attribute Description
Connector RJ-45
Number of ports One RS 232 port and one RS485 port
