Installation Manual
Quidway S8500 Series Routing Switches Appendix B Installation of B68 Cabinet
Huawei Technologies Proprietary
B-9
Caution:
It is required to remove the top covers before combining cabinets. After combination,
top covers are to be installed again.
B.2.6 Cabinet Fastening
I. Installing anchor plate
Install the anchor plate of the B68-22 cabinet according to Figure B-10. Press the
anchor plate against the cabinet feet. Two anchor plates are required for one cabinet.
Caution:
The anchor plate must be installed in the direction as shown in Figure B-10.
