Quidway S8500 Series Routing Switches Chapter 1 Product Overview
Huawei Technologies Proprietary
1-18
Table 1-21 CF status LED
LED Status
ON
The CF card is in position and is idle. You cannot remove the
card.
Blinking
The CF card is in position and reading/writing data. You
cannot remove the card.
CFS
OFF
The CF card is out of position or offline (you can force the
in-position CF card to go offline using the appropriate
background command). You can remove/insert the card.
z
Status LEDs for LPU modules
The SRP1N1 module has eight pairs of LEDs to indicate the operating status of eight
LPU modules.
Table 1-22 Status LEDs for LPU modules
LED Status
ON The module is faulty.
OFF The module is faulty or out of position.
Blinking (1s) The module is running normally.
RUN
Fast blinking
(125ms)
The module is booting or not registered
successfully.
ON The module has alarms.
ALM
OFF The module has no alarms or is out of position.
0~3, 6~9 Indicate slots 0 through 3 and slots 6 through 9
z
Status LEDs for the SRP1N1 module
You can learn the operating status of SRP1N1 module by reading the SFS, ACT, ALM
and RUN LEDs on it. The following table gives a summary of the four LEDs.
Table 1-23 Status LEDs for the SRP1N1 module
SRP1N1 LED Status
ON The switching fabric unit is active.
SFS
OFF The switching fabric unit is standby.
Green The SRP1N1 module is faulty.
OFF The SRP1N1 module is faulty.
RUN
Green blinking The SRP1N1 module runs normally.
