Table 2-41 Optical port modules available for the SP4 module
SFP module
Central
wavelength
Connector
Matching
cable
Transmission
distance
50/125 µm
multimode
optical fiber
cable
2.5GBASE-FX-MM
-SFP
62.5/125 µm
multimode
optical fiber
cable
2 km (1 mi)
2.5GBASE-FX-SM-
SFP
15 km (9 mi)
2.5GBASE-FX-SM-
LR-SFP
1310 nm
40 km (25 mi)
2.5GBASE-FX-SM-
VR-SFP
1550 nm
LC
9/125 µm
single mode
optical fiber
cable
80 km (50 mi)
2.16 UP1 Module
2.16.1 Specifications
The UP1 module provides one 10 Gbps POS optical ports.
Table 2-42 UP1 module specifications
Attribute UP1
CPU MPC8245
Boot ROM 512 KB
SDRAM 256 MB
Dimensions (L × W) 366.7 × 340 mm (14.4 × 13.4 in)
Max. power consumption 92 W
Number of ports One
Connector XFP/LC
Rate 10 Gbps
