Quidway S8500 Series Routing Switches Chapter 1 Product Overview
Huawei Technologies Proprietary
1-28
Figure 1-13 Front panel of the NAT service processor card
Figure 1-14 Rear panel of the NAT service processor card
II. VPLS service processor card (LSB1VPNB)
1) Technical specifications
The VPLS service processor card provides no external port.
Table 1-41 Technical specifications of the VPLS service processor card
Attribute VPN
CPU MPC755
Boot ROM 512 KB
SDRAM 512 MB
Dimensions (L × W) 366.7 × 340mm (14.4 × 13.4 in)
2) Front and rear panels
Figure 1-15 Front panel of the VPLS service processor card
Figure 1-16 Rear panel of the VPLS service processor card
1.2.8 System Specifications
The following table summarizes the physical specifications of the S8500 series.
