Installation Manual
Quidway S8500 Series Routing Switches Appendix B Installation of B68 Cabinet
Huawei Technologies Proprietary
B-27
(1) Retaining nut of the cabinet (2) Cabinet foot
re frame of the cabinet
F ing
B.3.7 Cabinet Combination Connection
When two or more cabinets are to be combined, combination connection between
(3) Retaining nut of anchor plate (4) Lower enclosu
igure B-29 Cabinet feet fasten
cabinets should be conducted. As shown in Figure B-30, first remove top covers of all
cabinets, then rotate the combining plates on top of the cabinets by 180° and fasten
them, and use flat washer, spring washer, bolt and nut to combine the combining plates
as shown in Figure B-31. Figure B-30 shows the position of combining plate before it is
rotated, and Figure B-31 shows the its position after it has been rotated.
