Installation Manual
Quidway S8500 Series Routing Switches Chapter 3 Installation Preparation
Huawei Technologies Proprietary
3-6
3.3 Installation Tools
Table 3-3 Required installation tools
Measure
and
lineation
tools
Long tape, ruler (1 meter in length), gradienter, marking
pen, powder marker, pencil
Drills
One percussion drill, several drill bits, one vacuum
cleaner
Fastening
tools
Flat-blade screwdriver P4 -- 75 mm
Phillips screwdriver P1 -- 100mm, P2 -- 150mm and P3
-- 250mm
Socket wrench M5
Box-end wrench M6
Double ring spanner (10-12) or open-end wrench
(10-12)
Small tools
Sharp-nose pliers, diagonal pliers, vices, hand-held
electric drill, file, handsaw, crowbar, rubber hammer
General
tools
Auxiliary
tools
Brush, tweezers, paper knife, hand bellows, electric
iron, solder wire, fork, ladder
Special tools
ESD-preventive wrist strap, cable stripper, crimping
pliers, RJ-45 crimping pliers, wire punchdown tool
Meters
Multimeter, 500V Meg-ohmmeter (used for measuring
the insulation resistance), error detector, optical power
meter, earth resistance tester
 Note:
The instruments and tools are not shipped with the S8500 series and it is up to the
users to ensure their availability.
