Quidway S8500 Series Routing Switches Chapter 1 Product Overview
Huawei Technologies Proprietary
1-14
Table 1-13 Status LEDs for LPU modules
LED Status
ON The module is faulty.
OFF The module is faulty or out of position.
Blinking (1s) The module is running normally.
RUN
Fast blinking (125
ms)
The module is booting or not registered
successfully.
ON The module has alarms.
ALM
OFF The module has no alarms or is out of position.
0~5,
8~13
Indicate slots 0 through 5 and slots 8 through 13
z
Status LEDs for the SRP1N0 module
You can learn the operating status of SRP1N0 module by reading the SFS, ACT, ALM
and RUN LEDs on it. The following table gives a summary of the four LEDs.
Table 1-14 Status LEDs for the SRP1N0 module
SRP1N0 LED Status
ON The switching fabric unit is active.
SFS (unavailable
yet)
OFF The switching fabric unit is standby.
Green The SRP1N0 module is faulty.
OFF The SRP1N0 module is faulty.
RUN
Green blinking The SRP1N0 module runs normally.
Red The SRP1N0 module has alarms.
ALM
OFF The SRP1N0 module has no alarms.
Green The SRP1N0 module is active.
ACT
OFF The SRP1N0 module is standby.
II. SRP1N1 module
1) Specifications
The S8508 uses SRP1N1 modules. The following table summarizes the board
specifications.
