Installation Manual
Quidway S8500 Series Routing Switches Chapter 4 Switch Installation
Huawei Technologies Proprietary
4-8
Step 5: Lift the switch a little higher than the cabinet shelf, put it on the shelf, and push
it into the cabinet.
Step 6: Align the mounting ears with the square holes in the posts of the cabinet, and
fasten the screws in the holes to fix the switch in the cabinet.
4.4 Mounting the Switch in Huawei B68 Cabinet
When purchasing the S8500 series, you may also select a Huawei B68 Series Cabinet
as needed. There are two types of B68 cabinets available for the S8500 series:
z
B68-18 model: 1.8 m B68 cabinet (600 x 800 x 1800 mm, or 23.6 x 31.5 x 70.9 in.)
z
B68-22 model: 2.2 m B68 cabinet (600 x 800 x 2200 mm or 23.6 x 31.5 x 86.7 in.)
 Note:
Except for the height, B68-18 and B68-22 cabinets have the same requirements in
space planning, cabinet positioning, and fixing.
4.4.1 Installing B68 Cabinet
For the procedure of installing a B68 cabinet, refer to Appendix B.
4.4.2 Cabinet Remodel Introduction
Refer to
Quidway S8500 B68-18 Cabinet Remodel Introduction
and
Quidway S8500
B68-22 Cabinet Remodel Introduction for details.
4.5 Connecting PGND Wire and Power Cord
4.5.1 Connecting PGND Wire
Caution:
For the safety of operators and equipment, the switch must be well grounded. The
resistance reading between switch chassis and the ground must be less than 1 ohm.
I. Common grounding environment
Step 1: Remove the screw from the grounding hole in the switch chassis.
To Next Page
