Item Description Default Value Value Range
Single battery
voltage(V)
Species the voltage of each
battery that is connected in
series in a battery string.
12 V 2, 6, 12
Single battery
capacity(Ah)
Species the capacity of each
battery that is connected in
series in a battery string.
Depends on
the actual
model.
5–9999
Batteries in a
battery string
Species the number of
batteries in a battery string.
Depends on
the model.
The value
range depends
on the model.
Number of
battery
strings
Species the number of
battery strings connected in
parallel.
1 1–6
Installation
time
A battery maintenance
reminder is displayed when
the maintenance time
(counted from the
installation time) comes.
- -
Maintenance
period(d)
Species the interval for
reminding users of battery
maintenance.
0 0–365
Cell oat
voltage(V/
cell)
Species the battery oat
charging voltage.
2.25 2.23–2.30
Cell equalized
volt.(V/cell)
Species the battery
equalized charging voltage.
2.35 2.30–2.40
Dis. curr. 0.1C
EOD(V/cell)
Species the EOD threshold
when the discharge current is
0.1C, 0.3C, 0.5C, or 1.0C
respectively.
1.80 1.80–1.90
Dis. curr. 0.3C
EOD(V/cell)
1.80 1.80–1.90
Dis. curr. 0.5C
EOD(V/cell)
1.75 1.75–1.85
Dis. curr. 1.0C
EOD(V/cell)
1.60 1.60–1.75
Shallow
discharge test
When certain conditions are
met, the charger shuts down,
and batteries supply power
to loads. The system records
the battery discharge data as
a reference for battery
capacity and lifespan.
Disable Disable,
Enable
