Huawei UPS5000-E-30 kVA - A Power Distribution Silkscreen Description

A Power Distribution Silkscreen
Description
The silk screen content is in the format of route number + symbol + switch
sequence number. In the single-input scenario, the route number is omitted by
default. For example, 1QF1 indicates the rst switch of route I, 2QF1 indicates the
rst switch of route II, and QF1 indicates the rst switch in the single-input
scenario.
Table A-1 Symbol description
Symbol
Name Symbol Name
QF Circuit breaker QFS SPD circuit breaker
FS SPD FU Fuse
MCCB Molded case circuit
breaker
- -
