Item Description
SPD/SYSOUT switch function If the SPD/SYSOUT switch is set to Enable, this
parameter is displayed on the screen. Set this
parameter to determine whether the port is
used to detect the status of the PDC input SPD
or system output circuit breaker.
MUE05A DI type congure Customize the initial status of Battery ground
fault [BTG], D.G. connection [GEN], PDC
output breaker [OUT], PDC maintenance
breaker [MT], BP/SYSMT switch, and SPD/
SYSOUT switch based on site requirements.
MUE06A connection Species the MUE06A connection status. The
mains and bypass backfeed protection is
enabled only when this parameter is set to
Enable.
MUS05A DO_1 Action,
MUS05A DO_2 Action,
MUS05A DO_3 Action,
MUS05A DO_4 Action
Controls the status of DO ports on the MUS05A
dry contact card.
MUE07A DO_1 Action,
MUE07A DO_2 Action,
MUE07A DO_3 Action,
MUE07A DO_4 Action,
MUE07A DO_5 Action
Controls the status of DO ports on the MUE07A
dry contact extended card.
MUS05A DO_1, MUS05A
DO_2, MUS05A DO_3,
MUS05A DO_4
Corresponds to the signal of the output dry
contact DO on the MUS05A.
MUE07A DO_1, MUE07A
DO_2, MUE07A DO_3,
MUE07A DO_4, MUE07A
DO_5
Corresponds to the signal of the output dry
contact DO on the MUE07A.
MUE07A DI_1, MUE07A DI_2,
MUE07A DI_3, MUE07A DI_4,
MUE07A DI_5
Corresponds to the signal of the input dry
contact DI on the MUE07A.
4.2.4.8 User Settings
