Set system parameters with caution. Incorrect setting may aect the normal UPS
operation.
● Set Single/Parallel after double check. Incorrect settings may aect the normal
UPS operation.
● Output voltage level refers to the line voltage level. Set it based on site
requirements.
● Set Output frequency correctly. Otherwise, loads may be
aected and the UPS
may not work properly.
● Set all battery parameters correctly based on site requirements. Battery
parameter settings are critical to battery maintenance, battery lifespan, and
UPS discharge time.
Figure 5-1 Settings Wizard
UPS5000-E-(30 kVA–180 kVA)
User Manual (Integrated UPS) 5 Operations
Issue 02 (2022-12-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 127
