Indicator Color Status Description
Blinking
at short
interval
s
Modules are not congured, the inverter or
rectier software is being upgraded, or the
inverter software is being upgraded (blinking
at 4 Hz, on for 0.125s and o for 0.125s).
O The rectier software is being upgraded.
Alarm
indicator
Yellow Steady
on
A minor alarm is generated for the inverter or
rectier.
O There is no minor alarm for the inverter or
rectier, or the rectier software is being
upgraded.
Fault
indicator
Red Steady
on
A critical alarm is generated for the inverter or
rectier.
O There is no critical alarm for the inverter or
rectier, or the rectier software is being
upgraded.
Functions
The power module consists of a PFC rectier and inverter. The power module
performs AC-DC or DC-DC conversion on the mains and battery inputs, and
stabilizes the bus voltage. The inverter converts DC inputs into AC sine wave
outputs.
Specications
● Dimensions (H x W x D): 87 mm x 442 mm x 620 mm
● Weight: < 21 kg
● Rated output capacity: 30 kVA/30 kW
● Power density: 20.64 W/inch
3
