Active Alarms
Figure 4-9 Active alarms
Historical Alarms
Figure 4-10 Historical alarms
Buzzer O
Two buzzer control options are available: Buzzer On and Buzzer O:
● If the buzzer is disabled, Buzzer On is displayed on the operation screen.
● If the buzzer is enabled, Buzzer
O is displayed on the operation screen.
If the buzzer is enabled, the buzzer buzzes when a critical or minor alarm is
generated. If the buzzer is disabled, the buzzer does not buzz in any case.
Twinkle
After you tap Twinkle, the UPS reports the address information to the
FusionModule app. The icon of the corresponding integrated UPS in the device
layout diagram on the app will blink for 10s.
