UPS5000-E-(50 kVA-300 kVA)
User Manual (50 kVA Power Modules)
Copyright © Huawei Technologies Co., Ltd.
For single mains, the copper bars between the mains and bypass input terminals do not
need to be removed, and bypass input cables do not need to be connected.
Step 12 Remove the signal cable trough cover from the cable entry cabinet.
Figure 3-61 Removing the cable trough cover
Step 13 Connect the signal cable.
