UPS5000-E-(50 kVA-300 kVA)
User Manual (50 kVA Power Modules)
2 Overview
Copyright © Huawei Technologies Co., Ltd.
41
Figure 2-25 COM2 pins
Table 2-9 COM2 pin definition
Pin
Description
1
RS485+
2
RS485–
3
N/A
4
RS485+
5
RS485–
6
GND
7
CANH0
8
CANL0
Figure 2-26 RS485 pins
