HUSABERG FE 570 EU - Installing the Spark Plug; Installing the Valve Cover; Installing the Oil Filter; Installing the Oil Screen

30/ENGINE ASSEMBLY 150
20.38Installing the spark plug
300296-10
– Mount and tighten the spark plug with the special tool.
Guideline
Spark plug M12x1.25 15… 20 Nm
(11.1…
14.8 lbf ft)
Spark plug wrench (75029172000) ( p. 271)
20.39Installing the valve cover
300295-10
– Position the valve cover seal.
– Position the valve cover. Mount and tighten screws .
Guideline
Screw, valve cover M6 10 Nm (7.4 lbf ft)
20.40Installing the oil filter
300294-11
– Fill oil filter  with engine oil and place in the oil filter housing.
300360-11
– Oil the O-ring of the oil filter cover.
– Mount the oil filter cover.
– Mount and tighten screws .
Guideline
Screw, oil filter cover M5 6 Nm (4.4 lbf ft)
20.41Installing the oil screen
300291-10
– Mount and tighten the oil drain plug with magnet  and the new sealing ring.
Guideline
Oil drain plug with magnet M12x1.5 20 Nm
(14.8 lbf ft)
– Thoroughly clean the plug and engine oil screen.
– Clean the sealing area on the engine.
– Mount and tighten engine oil screen plug  with the O-rings.
Guideline
Plug, engine oil screen M17x1.5 20 Nm
(14.8 lbf ft)
