HUSABERG FE 570 EU - 03;Frame; Removing the Engine Guard; Installing the Engine Guard

03/FRAME 30
6.1Removing the engine guard
100450-10
– Remove screw . Remove the engine guard.
6.2Installing the engine guard
100450-10
– Attach the engine guard on the frame at the rear and swing it up and forward.
Mount and tighten screw .
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
