HUSABERG FE 570 EU - 08;Mask, Fender, Decal; Removing the Front Fender; Installing the Front Fender; Removing the Start Number Plate (FE USA)

08/MASK, FENDER, DECAL 63
11.1Removing the front fender
(FE EU, FE AUS)
– Remove the headlight mask with the headlight. ( p. 88)
(FE USA)
– Remove the start number plate. ( p. 63)
300721-10
– Remove screws .
– Take out the brake line and wiring harness from the brake line guide.
(FE EU, FE AUS)
– Disconnect the front turn signal connector.
300722-10
– Remove screws . Take off the fender with the brake line guide.
Info
Pay attention to the location of the distance bushings.
11.2Installing the front fender
300722-11
– Ensure that the distance bushings are mounted in the brake line guide.
– Position the fender with the brake line guide.
– Mount and tighten screws .
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
– Position the brake line and wiring harness in brake line guide.
(FE EU, FE AUS)
– Join the front turn signal connector parts together.
300721-11
– Mount and tighten screws .
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
(FE EU, FE AUS)
– Install the headlight mask with the headlight. ( p. 88)
(FE USA)
– Install the start number plate. ( p. 64)
11.3Removing the start number plate (FE USA)
301333-11
– Remove screw  and take off the clamp.
– Remove screw . Take off the start number plate.
