HUSABERG FE 570 EU - Disassembling the Seal Ring Retainer

04/SHOCK ABSORBER, SWINGARM 38
200764-10
– Remove piston .
– Remove compression damping shim stack .
Info
Guide the compression damping shim stack onto a screwdriver and put
them aside together.
200765-10
– Remove rebound damping washer .
– Remove seal ring retainer .
200766-10
– Remove locking cap  and bump rubber .
7.15Disassembling the seal ring retainer
– Disassemble the piston rod. ( p. 37)
200785-10
– Remove rebound rubber .
– Remove centering disk .
200786-10
– Remove seal ring .
– Remove washer  from seal ring .
200787-10
– Remove washer .
– Remove O-ring .
– Remove dust boot .
