HUSABERG FE 570 EU - Removing the Swingarm, with Shock Absorber and Rear Wheel

04/SHOCK ABSORBER, SWINGARM 51
– Tighten the spring by turning the adjusting ring to the measured value deter-
mined when it was removed.
Hook wrench (T106S) ( p. 274)
200750-11
– Tighten screw .
Guideline
Screw, shock absorber adjusting ring M6 5 Nm (3.7 lbf ft)
7.28Removing the swingarm, with shock absorber and rear wheel
Condition
The motorcycle is jacked up.
The fuel tank has been removed.
300681-10
– Remove chain connecting link .
– Thread the chain out.
300682-10
– Remove screws .
– Remove screw .
– Remove the foot brake cylinder and allow it to hang tension-free to the side.
300683-10
– Remove screw .
300684-10
– Remove the cable binders.
– Separate plug-in connector  of the brake light switch.
