TECHNICAL DATA - ENGINE TIGHTENING TORQUES 222

Screw, cable holder in generator cover M4 4 Nm (3 lbf ft)

Loctite

243™

Locking screw for bearing M5 6 Nm (4.4 lbf ft)

Loctite

243™

Oil jet, piston cooling M5 2 Nm (1.5 lbf ft)

Loctite

243™

Oil jet, rocker arm lubrication M5 2 Nm (1.5 lbf ft)

Loctite

243™

Screw, ignition pulse generator M5 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, locking lever M5 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, oil filter cover M5 6 Nm (4.4 lbf ft) –

Screw, oil pump cover M5 6 Nm (4.4 lbf ft)

Loctite

222

Nut, water-pump wheel M6 8 Nm (5.9 lbf ft)

Loctite

243™

Plug, water pump drain hole M6 10 Nm (7.4 lbf ft) –

Screw, camshaft bearing support M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, clutch cover M6x25 10 Nm (7.4 lbf ft) –

Screw, clutch cover M6x30 10 Nm (7.4 lbf ft) –

Screw, clutch cover M6x65 10 Nm (7.4 lbf ft) –

Screw, clutch spring M6 10 Nm (7.4 lbf ft) –

Screw, cylinder head M6 10 Nm (7.4 lbf ft) –

Screw, engine housing M6x60 10 Nm (7.4 lbf ft) –

Screw, engine housing M6x70 10 Nm (7.4 lbf ft) –

Screw, engine housing M6x75 10 Nm (7.4 lbf ft) –

Screw, generator cover M6x30 10 Nm (7.4 lbf ft) –

Screw, generator cover M6x50 10 Nm (7.4 lbf ft) –

Screw, generator cover (chain shaft

through-hole)

M6x30 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, idler M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, shift drum locating M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, shift lever M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, starter motor M6 10 Nm (7.4 lbf ft) –

Screw, stator bracket M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, timing chain guide rail M6 8 Nm (5.9 lbf ft)

Loctite

243™

Screw, timing chain securing guide M6 8 Nm (5.9 lbf ft)

Loctite

243™

Screw, timing chain tensioning rail M6 8 Nm (5.9 lbf ft)

Loctite

243™

Screw, torque limiter M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, valve cover M6 10 Nm (7.4 lbf ft) –

Screw, water pump cover M6x25 10 Nm (7.4 lbf ft) –

Screw, water pump cover M6x55 10 Nm (7.4 lbf ft) –

Oil jet, conrod lubrication M6x0.75 4 Nm (3 lbf ft) –

Plug, oil channel M7 9 Nm (6.6 lbf ft)

Loctite

243™

Screw, rocker arm bearing M7x1 15 Nm (11.1 lbf ft) –

Plug, crank shaft location with thick

copper disk

M8 10 Nm (7.4 lbf ft) –

Plug, oil channel M10 15 Nm (11.1 lbf ft)

Loctite

243™

Screw, engine sprocket M10 60 Nm (44.3 lbf ft)

Loctite

243™

Balancer shaft nut M10x1 40 Nm (29.5 lbf ft) –

Screw, unlocking of timing chain ten-

sioner

M10x1 10 Nm (7.4 lbf ft) –
