HUSABERG FE 570 EU - 05;Exhaust; Removing the Main Silencer; Installing the Main Silencer; Removing the Exhaust System

05/EXHAUST 54
8.1Removing the main silencer
Warning
Danger of burns The exhaust system gets very hot when the vehicle is driven.
– Allow the exhaust system to cool down. Do not touch hot components.
100443-10
– Disconnect spring .
– Remove screws  and take off the main silencer.
8.2Installing the main silencer
100443-11
– Mount the main silencer. Mount and tighten screws .
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
– Reconnect spring .
8.3Removing the exhaust system
– Remove the main silencer. ( p. 54)
– Remove the shock absorber. ( p. 34)
– Take off the throttle valve body and allow it to hang to the side. ( p. 161)
300676-10
– Disconnect connector  of the lambda sensor. Open the cable binders.
300677-10
– Remove screw .
– Unscrew screw .
