WIRING DIAGRAM 261
Component:
B8 Wheel speed sensor B1‑2
H2 Turn signal, front left E1
H3 Turn signal, front right B‑C1
H4 Turn signal indicator lamp C1
H5 Turn signal, rear right C8
H6 Turn signal, rear left E8
H7 High beam indicator light C1
H8 Parking light D1
H9 Low beam/high beam D1
H10 Horn E6
H11 License plate lamp D‑E8
H12 Brake/tail light D8
K3 Turn signal relay E2
P1 Speedometer A‑B1
S2 Brake light switch, front E3
S4 Turn signal switch E3
S5 Horn button, light switch, short circuit button E4‑5
S6 Brake light switch, rear E7
Cable colors:
1 Brown
2 Brown
3 Yellow-blue
4 Black
5 Black
6 Black
7 Black
8 Purple
9 Purple
10 Purple
11 Purple
12 Black-orange
13 Brown
14 Brown
15 Yellow-blue
16 Yellow
17 Brown
18 Brown
19 White
20 White-green
21 White-green
22 Yellow-blue
23 Black-yellow
24 Yellow-blue
25 Gray
26 Yellow-blue
27 Yellow-blue
28 Brown
29 Brown
30 Brown
31 Brown
32 Brown
