13/BRAKE SYSTEM 81
Warning
Danger of accidents Reduced braking due to use of non-approved brake linings.
– Brake linings available from accessory suppliers are often not tested and approved for use on HUSABERG vehicles. The
construction and friction factor of the brake linings and therefore the brake power can differ considerably from the original
HUSABERG brake linings. If brake linings are used that differ from the originals, there is no guarantee that they comply
with the original license. The vehicle no longer corresponds to the condition at delivery, and the warranty is no longer valid.
Warning
Environmental hazard Hazardous substances cause environmental damage.
– Oil, grease, filters, fuel, cleaners, brake fluid, etc., should be disposed of as stipulated in applicable regulations.
Info
Never user DOT 5 brake fluid! This is based on silicone oil and is colored purple. Oil seals and brake lines are not designed for
DOT 5 brake fluid.
Avoid contact between brake fluid and painted parts. Brake fluid attacks paint!
Use only clean brake fluid from a sealed container!
100395-10
– Move the brake fluid reservoir mounted on the handlebar to a horizontal position.
– Remove screws .
– Remove cover with membrane .
– Press the brake caliper by hand on to the brake disc in order to press back the
brake pistons. Ensure that brake fluid does not overflow from the brake fluid reser-
voir, using suction to remove it if it does.
Info
Make sure when pushing back the brake pistons that you do not press the
brake caliper against the spokes.
100396-10
– Remove locking split pins , withdraw bolt , and take out the brake pads.
– Clean the brake caliper and brake caliper support.
100397-01
– Check that leaf spring in the brake caliper and sliding plate in the brake
caliper support are seated correctly.
100398-10
– Fit the brake pads, insert the bolt, and mount the locking split pins.
– Operate the hand brake lever repeatedly until the brake linings lie on the brake disc
and there is a tight spot.
