HUSABERG FE 570 EU - Page 95

30/ENGINE 93
300695-10
– Remove spring .
300702-10
– Take off the spark plug connector.
– Disconnect coolant temperature sensor connector .
300696-10
– Expose the cable.
– Separate plug-in connector  of the ignition pulse generator.
300697-10
– Separate plug-in connector  of the generator.
300698-10
– Remove screws .
– Take off the engine braces and washers.
300699-10
– Remove screw .
Info
Do not lose the sleeves.
