HUSABERG FE 570 EU - Page 97

30/ENGINE 95
– Tighten screw .
Guideline
Engine carrying screw M10 60 Nm
(44.3 lbf ft)
– Tighten screws .
Guideline
Screw, engine brace M8 33 Nm
(24.3 lbf ft)
300685-12
– Tighten the swingarm pivot nut.
Guideline
Nut, swingarm pivot M16x1.5 100 Nm
(73.8 lbf ft)
300697-11
– Join plug-in connector  of the generator.
– Route the cable so it is tension-free and secure it with cable binders.
300696-11
– Join plug-in connector  of the ignition pulse generator.
– Route the cable so it is tension-free and secure it with cable binders.
300706-10
– Connect the spark plug connector.
– Connect coolant temperature sensor connector .
300803-10
– Mount spring .
