IAI SCON-CA - Page 333

Chapter 10 Appendix
323
Motor
Output
Lead
Maximum
Speed
Maximum
Acceleration/
Deceleration Speed
Minimum
Pressing
Force
Maximum
Pressing
Force
Rated
Pressing
Speed
Actuator
Series
Type
[W]
No. of
Encoder
Pluses
[mm]
Oriented
Direction
[mm/s] [G] [N] [N] [mm/s]
Horizontal
1.0
− − −
16
Vertical
800
0.7
− − −
Horizontal
0.6
− − −
8
Vertical
400
0.5
− − −
Horizontal
0.5
− − −
SXM
SYM
60 16384
4
Vertical
200
0.3
− − −
8 Vertical 400 0.3
− − −
SZM 60 16384
4 Vertical 200 0.3
− − −
Horizontal
1.0
− − −
20
Vertical
1000
(at 100 to 700st)
795 (at to 800st)
645 (at to 900st)
540
(at to 1000st)
0.8
− − −
Horizontal
0.6
− − −
10
Vertical
500
(at 100 to 600st)
480 (at to 700st)
380 (at to 800st)
310 (at to 900st)
255
(at to 1000st)
0.5
− − −
Horizontal
0.5
− − −
MXM
MYM
100 16384
5
Vertical
250
(at 100 to 600st)
220 (at to 700st)
175 (at to 800st)
145 (at to 900st)
120
(at to 1000st)
0.3
− − −
10 Vertical
500
(at 100 to 600st)
480
(at to 700st)
380 (at 800st)
310 (at 900st)
255 (at 1000st)
0.5
− − −
ISA
ISPA
(Slider Type)
MZM 100 16384
5 Vertical
250
(at 100 to 600st)
220
(at to 700st)
175 (at 800st)
145 (at 900st)
120 (at 1000st)
0.3
− − −
