8. Parameter
290
[20] PIO pattern selection (Parameter No.25)
No. Name Symbol Unit Input Range
Default factory
setting
25 PIO pattern selection IOPN – 0 to 7 0 (Standard Type)
Select the PIO operation pattern in Parameter No.25.
Check the 3.2 Operation in Positioner Mode for details of PIO patterns.
Pattern type
Value set in
Parameter
No.25
Mode Feature of PIO pattern
PIO
pattern 0
0
(factory
setting)
Positioning mode
(Standard type)
• Number of positioning points: 64
• Position command: Binary code
• Zone signal output: 1 point
• Position zone signal output: 1 point
PIO
pattern 1
1
Teaching mode
(Teaching type)
• Number of positioning points: 64
• Position command: Binary code
• Position zone signal output: 1 point
• Jog operation enabled by PIO signal
• Writing current position data to position table
enabled by PIO signal
PIO
pattern 2
2
256-point mode
(256-point type)
• Number of positioning points: 256
• Position command: Binary code
• Position zone signal output: 1 point
PIO
pattern 3
3
512-point mode
(512-point type)
• Number of positioning points: 512
• Position command: Binary code
• Zone signal output: None
PIO
pattern 4
4
Solenoid valve mode 1
(7-point type)
• Number of positioning points: 7
• Position command: Individual No. signal ON
• Zone signal output: 1 point
• Position zone signal output: 1 point
PIO
pattern 5
5
Solenoid valve mode 2
(3-point type)
• Number of positioning points: 3
• Position command: Individual No. signal ON
• Signal equivalent to LS (limit switch) enabled
• Zone signal output: 1 point
• Position zone signal output: 1 point
PIO
pattern 6
6
Pressing operation
using force sensor
mode 1
• Number of positioning points: 32
• Position command: Binary code
• Position zone signal output: 1 point
• Judgment of pressing force enabled
PIO
pattern 7
7
Pressing operation
using force sensor
mode 2
(Solenoid valve Type)
• Number of positioning points: 5
• Position command: Individual No. signal ON
• Position zone signal output: 1 point
• Judgment of pressing force enabled
Pulse train mode
PIO
pattern 0
0
Incremental type
for actuator pulse train
control mode
PIO
pattern 1
1
Absolute type
for actuator pulse train
control mode
Refer to 3.3 Opetration in Pulse Train Control
Mode (Only for Types up to 750W) for details.
