IAI SCON-CB-F User Manual

1. Specications Check
25
1.1.2 Teaching Tool
A teaching tool such as PC software is necessary when performing the setup for position setting,
parameter setting, etc. that can only be done on the teaching tool.
Please prepare either of the following teaching tools such as PC software.
No. Part Name Model
1
PC Software
(Includes RS232C Exchange Adapter + Peripheral Communication Cable)
RCM-101-MW
2
PC Software
(Includes USB Exchange Adapter + USB Cable + Peripheral Communication Cable)
RCM-101-USB
3 Data Setter TB-03 (Wired Link) TB-03
4 Touch Panel Teaching TB-02
5 Touch Panel Teaching (with deadman switch) TB-02D
6 Touch Panel Teaching TB-01
7 Touch Panel Teaching (with deadman switch attached on the left) TB-01D
8 Touch Panel Teaching (with deadman switch attached on the right) TB-01DR
9 Touch Panel Teaching CON-PTA
10 Touch Panel Teaching (with deadman switch) CON-PDA
11
Touch Panel Teaching
(with deadman switch + TP adapter (RCB-LB-TGS))
CON-PGAS
1.1.3 lnstruction Manuals Related to this Product, which are Contained in
the Instruction Manual (DVD).
No. Name Manual No.
1 SCON-CB/CGB/LC/LCG Controller Instruction Manual ME0340
2 RCON System Instruction Manual ME0384
3 PC Software RCM-101-MW/ RCM-101-USB Instruction Manual ME0155
4
Data Setter TB-03 Position Controller, ELECYLINDER Wired Link
Instruction Manual
ME0376
5
Touch Panel Teaching TB-02/02D Applicable for Position Controller,
ELECYLINDER Instruction Manual
ME0355
6
Touch Panel Teaching to Apply for TB-01/01D/01DR Position Controllers
Instruction Manual
ME0324
7 Touch Panel Teaching CON-PTA/PDA/PGA Instruction Manual ME0295
8 DeviceNet Instruction Manual ME0256
9 CC-Link Instruction Manual ME0254
10 PROFIBUS-DP Instruction Manual ME0258
11 CompoNet Instruction Manual ME0220
12 MECHATROLINK-Ⅰ/Ⅱ Instruction Manual ME0221
13 EtherCAT Instruction Manual ME0273
14 EtherNet/IP Instruction Manual ME0278
15 PROFINET IO Instruction Manual ME0333
16 Instruction Manual for the Serial Communication [for Modbus] ME0162
17 MECHATROLINK-Ⅲ Instruction Manual ME0317
18 LC Ladder Programming Manual ME0329
19 LC Ladder Edit Software Manual ME0330
