2.4.2 I/O Signals in LC Type
The table below shows the signal assignment of the flat cable. Follow the following table to connect the external
equipment (such as PLC).
Refer to LC Ladder Programing Manual (ME0329) provided separately for how to assign memories
in built-in ladder or how to use it.
Pin
No.
Category I/O No. Signal Name Function Description
Relevant
Sections
1A 24V
Power Supply Power Supply for I/O +24V
2A 24V
Power Supply Power Supply for I/O +24V
3A
4A
NC
Not used
－
5A IN0 X000
6A IN1 X001
7A IN2 X002
8A IN3 X003
9A IN4 X004
10A IN5 X005
11A IN6 X006
12A IN7 X007
13A IN8 X008
14A IN9 X009
15A IN10 X00A
16A IN11 X00B
17A IN12 X00C
18A IN13 X00D
19A IN14 X00E
20A
General
Input
IN15 X00F
They are 24V general-purposed input
terminals.
Assign to the built-in ladder and use them if
necessary.
1B OUT0 Y000
2B OUT1 Y001
3B OUT2 Y002
4B OUT3 Y003
5B OUT4 Y004
6B OUT5 Y005
7B OUT6 Y006
8B OUT7 Y007
9B OUT8 Y008
10B OUT9 Y009
11B OUT10 Y00A
12B OUT11 Y00B
13B OUT12 Y00C
14B OUT13 Y00D
15B OUT14 Y00E
16B
General
Output
OUT15 Y00F
They are 24V general-purposed output
terminals.
Assign to the built-in ladder and use them if
necessary.
Refer to
LC Ladder
Programing Manual
provided
separately
17B
18B
NC
Not used －
19B 0V
Power Supply
Power Supply for I/O 0V
20B 0V
Power Supply
Power Supply for I/O 0V
To Next Page
