1.1.4 How to Read the Model Plate
1.1.5 How to Read the Model of the Controller
Note 1: There is only safety categories applicable (CGB) type in the lineup for those types for
3000W and above.
Note 2: Standard type (CB) and safety category applicable type are available to connect for RCON
Connection Type.
Model
Serial numbe
r
MODEL : SCON-CB-100WAIHA-NP-5-2
SERIALNo. : 800056144 L11
INPUT : 1φ, 100-115V,50/60Hz, 1.8A
OUTPUT : 3φ, 0-90V, 0-333Hz, 1.10A
S C O N
–
C B
–
20W
A
I H A -NP-3-1
–
**
<Series>
<Type
(Note 1)
>
CB : Standard Type
CGB : Safety Category Compliant Type
LC : PLC Feature Equipped Type
LCG : PLC Feature Equipped Type
Safety Category Compliant Type
<Actuator Characteristics>
[Motor Type]
12 : 12W 200S : 200W (LSA/DD)
20 : 20W 300S : 300W (LSA)
30D : 30W (Excluding RS) 400 : 400W
30R : 30W (for RS) 600 : 600W
60 : 60W 750 : 750W
100 : 100W 750S : RCS2-RA13R
100S : 100W (LSA) with Loadcell
150 : 150W 3000 : 3000W
200 : 200W 3300 : 3300W
<Encoder Type>
WAI : Battery-less Absolute/Incremental
A : Absolute
G : Spurious Absolute
<Option>
Not Indication : Standard Type
HA : High Accel/Decel Type
I : Index Absolute Type (DD)
M : Multi-Rotation Absolute Type (DD)
<Identification for IAI use only>
* There is no identification in some
cases.
<Power-supply Voltage>
1: Single-phase 100V AC
2: Single-phase 200V AC
3: Three-phase 200V AC
<I/O Cable Length>
0: Equipped with no cable
2: 2m (Standard)
3: 3m
5: 5m
<I/O Signal Pattern>
NP : NPN Type (Sync. Type) (Standard)
PN : PNP Type (Source Type)
DV : DeviceNet Connection Type
CC : CC-Link Connection Type
PR : PROFIBUS-DP Connection Type
CN : CompoNet Connection Type
ML : MECHATROLINK-Ⅰ/Ⅱ
Connection Type
ML3 : MECHATROLINK-Ⅲ(motion)
Connection Type
EC : EtherCAT Connection Type
EP : EtherNet/IP Connection Type
PRT : PROFINET-IO Connection Type
RC : RCON Connection Type
(Note 2)
