IAI SCON-CB-F User Manual

1. Specications Check
27
1.2 Basic Specifications
1.2.1 Specifications
SCON-CB/CGB/LC/LCG
Item
Less than 400W 400 to 750W 3000W or more
Corresponding Motor Capacity 12W to 399W 400W to 750W 3000W to 3300W
Power-supply Voltage
Single-Phase 100 to 115V AC
Single-Phase 200 to 230V AC
(Fluctuation of power supply
±10% or less)
Single-Phase 200 to 230V AC
(Fluctuation of power supply
±10% or less)
Three Phase 200 to 230V AC
(Fluctuation of power supply
±10% or less)
Power-supply Voltage
100V AC
Rush Current
Power-supply Voltage
200V AC
30A (Controller side)
(Note 1)
,
80A (Drive side)
(Note 1)
30A (Controller side)
(Note 1)
,
80A (Drive side)
(Note 1)
40A (Controller side),
40A (Drive side)
Leak Current
(Note 2)
(Primary side when noise filter is
connected to power supply line)
3.0mA 3.5mA
Load Capacity and Heat Generation Refer to Power Capacity and Heat Generation
Power Supply Frequency 50/60Hz
PIO Power Supply
(Note 3)
24V DC ±10%
Power Supply for Electromagnetic
Brake
(for actuator equipped with brake)
24V DC ±10% 1A (MAX.)
(supplied from external equipment)
24V DC ±10% 1A (MAX.)
(supplied from external
equipment)
Supply of 1.5A is necessary
separately also for the
actuator.
Transient Power Cutoff Durability 20ms (50Hz), 16ms (60Hz)
Motor Control System Sine Wave PWM Vector Current Control
Corresponding Encoder
Incremental Serial Encoder
Absolute Serial Encoder
Battery-less Absolute Encoder
ABZ (UVW) Parallel Encoder
Incremental Serial Encoder
Absolute Serial Encoder
Battery-less Absolute
Encoder
Actuator Cable Length MAX. 20m
Serial Communication Interface
RS485 : 1CH (based on Modbus Protocol RTU/ASCII) Speed : 9.6 to 230.4Kbps
Control available with serial communication in the modes other than the pulse train
PIO Type
Signal I/O dedicated for 24V DC (selected from NPN/PNP) … Input 16 points max., output 16
points max.
External Interface
Field Network
Type
DeviceNet, CC-Link, PROFIBUS, CompoNet, MECHATROLINK-Ⅰ/Ⅱ, EtherCAT,
EtherNet/IP, PROFINET IO
Other RCON Connection Type
Data Setting and Input PC Software, Touch Panel Teaching, Teaching Pendant
SCON-
CB/CGB
Data Retention
Memory
Saves position data and parameters to non-volatile memory
(There is no limitation in number of writing.)
PIO Type
24V DC general-purposed signal I/O (Selection of NPN/PNP)
… Input 16 points max., output 16 points max. Insulation with Photocoupler
Field Network
Type
DeviceNet, CC-Link, PROFIBUS, CompoNet,
MECHATROLINK-Ⅰ/Ⅱ, EtherCAT, EtherNet/IP, PROFINET IO
Serial
Communication
Interface 2
• For display connection
RS485: 1CH…Modbus Protocol Based on RTU/ASCII
Speed: 9.6 to 230.4Kbps
Feedback
Pulse
Differential system (Line Driver System): MAX. 2.5Mpps
Open Collector System: MAX. 500Kpps (JM-08 when option
was used))
External Interface
Multi-Function Connector
Analog
Output
1 system (Load data)
4 to 20mA current output (±1%)
Load resistance 10 to 600Ω
Data Setting and Input
PC Software, LC Ladder Edit Software, Touch Panel
Teaching, Teaching Pendant
Program the number of steps 4K
SCON-
LC/LCG
Data Retention
Memory
Saves position data and parameters to non-volatile memory
(There is no limitation in number of writing.)
